| Model No: | LS9040KF |
| System Voltage: | 72V & 48V |
| Battery: | 100AH LFP Lithium |
| Controller: | 400A AC |
| Motor: | 5KW/7.5KW |
| Max.speed: | 25mph(40km/h) |
| Range: | 100kms |
| Climbing Ability: | 25% |
| Model No: | LS9040KF |
| System Voltage: | 72V & 48V |
| Battery: | 100AH LFP Lithium |
| Controller: | 400A AC |
| Motor: | 5KW/7.5KW |
| Max.speed: | 25mph(40km/h) |
| Range: | 100kms |
| Climbing Ability: | 25% |
| Place of Origin: | China |
| Brand Name: | Lexsong |
| Model Number: | LS9040KF |
| Certification: | CE |
| Minimum Order Quantity: | 1 |
| Packaging Details: | Steel Crate |
| Delivery Time: | 3-4 weeks |
Description:
Cheap Compact 4 Seats Electric Passenger Car LS9040KF has 60V/3KW AC system and 120Ah Maintenance Free Lead acid battery. It has plastic doors. It has electric power system which make steering very easy. It also has 4-wheel hydraulic front disc rear drum brake which ensure efficient braking force and safety. The chassis frame of the electric passenger car is galvanized and powder coated which ensure the anti-rust capability. Front laminated glass windshield with wiper ensures the visibility of the electric flatbed truck while driving. Digital instrument displays all necessary information of the electric passenger car the driver. The max.speed of this electric passenger car is 40km/h. The autonomy is more than 120kms per charge.
Applications:
Cheap Compact 4 Seats Electric Passenger Car LS9040KFcan be used in resorts, hotels, gardens, museums, parks, airports, stations, campus and other closed areas for moving people, if local authority allows, it also be used a family car.
Specifications:
| Key Components | |
| Battery | 5*12V120AH Maintenance Free Lead Acid Battery (LFP lithium battery is available) |
| Motor | 3KW AC Motor |
| Controller | AC controller |
| Performance | |
| Passenger capacity | 4 |
| Range (loaded) based on flat road at a speed of 20km/h (km)＊ | >120 |
| Max. speed (km/h) | 40 |
| Minimum turning radius (m) | 4.6 |
| Max. climbing ability (loaded) | 20% |
| Max. movement after brake at speed of 20km/h | ≤4m |
| Max. loading weight | 360kgs |
| Net weight | 620kgs |
| Dimensions | |
| Overall dimensions (mm) | 2900x1380x1620mm |
| Body and Frame | |
| Frame | Welded steel framework to be treated in galvanization and powder coating |
| Body | ABS plastic injection |
| Body structure | Integral frame structure |
| Door | Plastic with steel frame |
| Front Windshield | Laminated, with wiper |
| Side window | Safety glass, manual slided |
| Cabin top | Safety glass, can be opened |
| Backrest and cushion | sponge + artificial leather, adjustable |
| Floor | Aluminum |
| Seatbelt | 3-point |
| Dashboard | forward/reverse switch, battery capacity indicator, ignition key |
| Side rear view mirror | Two pieces per cart |
| Electric system | |
| Lighting system and horn | Front: 2 Headlights, 2 front turn signals, 2 fog lights; Back: 2 rear turn signals, 2 taillights(position light & brake light), 1 fog light, 1 reverse light),with DC-DC converter (converting from 60V to 12V) , horn. |
| Digital Meter | Voltameter, ammeter, speedometer, turn signal indicator, headlight indicator |
| Reversing alarm | |
| Audio system | Radio with USB/SD adaptor, with 2 speakers |
| Charger | Onboard charger, input 110V-240V~50Hz-60Hz, output 60V, 15-18A |
| Steering and Suspension | |
| Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function |
| Brake system | 4-wheel hydraulic brake, front disc brake, rear drum brake, with hand park brake |
| Accelerator | Stepless speed change |
| Suspension system | Front McPerson independent Rear integral shock damping |
| Driving mode | Rear axle two stage deceleration, motor direct driving |
| Wheel & Tyre | 145/70 R12 Tubeless Tire |
Headlight
Taillight and trunk
Dash Area
Waterproof Receptacle
Front suspension
Competitive Advantage:
What makes us different and better than other brands
Easier to Drive
Our Cheap Compact 4 Seats Electric Passenger Car LS9040KF has electric power steering system as standard which makes operating easier.
Safer
Our electric passenger car has 4-wheel hydraulic brake, front disc and rear drum brake
Lower Maintenance Cost
The batteries are sealed and maintenance free, which makes maintenance easier and cheaper.
Description:
Cheap Compact 4 Seats Electric Passenger Car LS9040KF has 60V/3KW AC system and 120Ah Maintenance Free Lead acid battery. It has plastic doors. It has electric power system which make steering very easy. It also has 4-wheel hydraulic front disc rear drum brake which ensure efficient braking force and safety. The chassis frame of the electric passenger car is galvanized and powder coated which ensure the anti-rust capability. Front laminated glass windshield with wiper ensures the visibility of the electric flatbed truck while driving. Digital instrument displays all necessary information of the electric passenger car the driver. The max.speed of this electric passenger car is 40km/h. The autonomy is more than 120kms per charge.
Applications:
Cheap Compact 4 Seats Electric Passenger Car LS9040KFcan be used in resorts, hotels, gardens, museums, parks, airports, stations, campus and other closed areas for moving people, if local authority allows, it also be used a family car.
Headlight
Taillight and trunk
Dash Area
Waterproof Receptacle
Specifications:
| Performance | |
| Passenger capacity | 4 |
| Range (loaded) based on flat road at a speed of 20km/h (km)＊ | >120 |
| Max. speed (km/h) | 40 |
| Minimum turning radius (m) | 4.6 |
| Max. climbing ability (loaded) | 20% |
| Max. movement after brake at speed of 20km/h | ≤4m |
| Max. loading weight | 360kgs |
| Net weight | 620kgs |
| Dimensions | |
| Overall dimensions (mm) | 2900x1380x1620mm |
| Body and Frame | |
| Frame | Welded steel framework to be treated in galvanization and powder coating |
| Body | ABS plastic injection |
| Body structure | Integral frame structure |
| Door | Plastic with steel frame |
| Front Windshield | Laminated, with wiper |
| Side window | Safety glass, manual slided |
| Cabin top | Safety glass, can be opened |
| Backrest and cushion | sponge + artificial leather, adjustable |
| Floor | Aluminum |
| Seatbelt | 3-point |
| Dashboard | forward/reverse switch, battery capacity indicator, ignition key |
| Side rear view mirror | Two pieces per cart |
| Electric system | |
| Lighting system and horn | Front: 2 Headlights, 2 front turn signals, 2 fog lights; Back: 2 rear turn signals, 2 taillights(position light & brake light), 1 fog light, 1 reverse light),with DC-DC converter (converting from 60V to 12V) , horn. |
| Digital Meter | Voltameter, ammeter, speedometer, turn signal indicator, headlight indicator |
| Reversing alarm | |
| Audio system | Radio with USB/SD adaptor, with 2 speakers |
| Charger | Onboard charger, input 110V-240V~50Hz-60Hz, output 60V, 15-18A |
| Steering and Suspension | |
| Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function |
| Brake system | 4-wheel hydraulic brake, front disc brake, rear drum brake, with hand park brake |
| Accelerator | Stepless speed change |
| Suspension system | Front McPerson independent Rear integral shock damping |
| Driving mode | Rear axle two stage deceleration, motor direct driving |
| Wheel & Tyre | 145/70 R12 Tubeless Tire |
