Factory supply lithium battery 2 seats electric cargo golf cart LS2043KHCX

Place of Origin:

China

Brand Name:

Lexsong

Model Number:

LS2043KHCX

Certification:

CE

Minimum Order Quantity:

1

Packaging Details:

Steel Crate

Delivery Time:

3-4 weeks

tp tp (3) tp (3) tp (3) tp (3) tp (3) tp (3) tp (3)

Place of Origin:

China

Brand Name:

Lexsong

Model Number:

LS2043KHCX

Certification:

CE

Minimum Order Quantity:

1

Packaging Details:

Steel Crate

Delivery Time:

3-4 weeks

tp tp (3) tp (3) tp (3) tp (3) tp (3) tp (3) tp (3)

Description:

Factory supply lithium battery 2 seats electric cargo golf cart LS2043KHCX, with manual lifted aluminum cargo box at the back, 12*7 Aluminum wheel and 100Ah lithium battery. It has 72V/5KW (optional 7.5KW) AC system which makes the cargo golf cart more powerful and efficient. Programmable AC 400A controller which makes the cargo golf cart more suitable for various terrains. Front double A-arm independent suspension, rear trailing arm suspension and shock absorber, and cold foam formed seat cushion make the cargo golf cartt more comfortable to drive. 4-wheel hydraulic disc brake, regeneration brake and EMB park brake make the cargo golf cart safer to ride. Galvanized and powder coated reinforced steel chassis frame and other steel brackets, and dacromet treated fasteners make the golf car more durable. Performance wise, this cargo golf cart has 30-40km/h maximum speed, 120kms driving range per charge, 25%-30% climbing ability. Various optional accessories are available to make the cargo golf cartt special and unique. Customization is also available



Applications:

Factory supply lithium battery 2 seats electric cargo golf cart LS2043KHCX can be in resorts, residential communities, farms, hotels, gardens, museums, parks, airports, stations, campuses and other enclosed areas for moving stuffs and tools, and maintenance, etc.

LED Headlight

LED Taillight

Multi-function Instrument

Dash Area

Sports Steering Wheel

Waterproof Receptacle

Front Independent Suspension

Rear Trailing Arm Suspension

Front Disc Brake

Lithium Battery

Tinted Split Windshield

Side mirror with LED light

Key Components
Battery 72V100AH LFP Lithium Battery (optional 48V150AH lead acid battery and 72V150AH Lithium battery)
Motor 5KW or 7.5KW AC Motor
Controller 400A AC Controller (Vanstar or Curtis)
Performance
Passenger capacity 2
Range (loaded) based on flat road at a speed of 20km/h (km)* >110
Max. speed (km/h) 32km/h (can be adjusted to 40km/h)
Minimum turning radius (m) 4.5
Max. climbing ability (loaded) 25%-30%
Max. movement after brake at speed of 20km/h ≤4m
Max. loading weight 480kgs
Net weight 570kgs
Dimensions
Overall dimensions (mm) 3180X1340X1890
Rear box dimensions (mm) 1400x1100x250
Min. ground clearance (mm) 150
Body and Frame
Frame Welded steel framework to be treated in galvanization and powder coating
Body PP plastic front body + PP plastic rear body
Roof PP injection, in beige color
Windshield Windshield, hinged
Roof Supports Carbon Steel, galvanization and powder coating
Backrest and cushion Cold formed sponge + mirco-fibre leather + plastic armrest
Floor Anti-slip Rubber
Dashboard in black plastic forward/reverse switch, battery capacity indicator, ignition key
Steering wheel Sports style, with carbon fibre finish
Beverage holders 4 cups drink holders
Glove box With lock
Side trim Plastic
Side rear view mirror Two pieces per cart, with LED light
Electric system
Lighting system and horn LED, 2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with 20A voltage reducer (converting from 72V to 12V), horn.
Digital Meter LCD Screen, Speedometer, Odometer, battery power meter and various indicators
Reversing alarm \
Charger Onboard charger, input 110V-240V~50Hz-60Hz, output 72V, 15-18A
Steering and Suspension
Steering system Single-stage rack and pinion steering system, automatic rocker compensating function
Brake system 4-wheel hydraulic disc brake, with automatic EM park brake and regenerative brake
Accelerator Stepless speed change
Suspension system Front double wishbone independent suspension, and rear trailing arm suspension with shock absorber
Driving mode Rear axle two stage deceleration, motor direct driving
Rear axle Integrated, Aluminum cage, Gear ratio 12.31:1
Wheel & Tyre 12x7 Alumimum wheel & 215/35-12
Various Optional Accessories for Choosing

Competitive Advantage:

What makes us different and better than other brands

More Powerful

Factory supply lithium battery 2 seats electric cargo golf cartS have 72V AC system, and the biggest motor can be 7.5KW (rated). Comparing to 36V/48V system, 72V AC is more powerful, that means our cargo golf cart can accelerate quicker, and run faster on slope or with full loading.

More Efficient

With the same output powerful, our cargo golf cart with 72V voltage needs smaller current. Smaller current means less heat emission from electric parts, so less energy consumption.

Lower Life Cost

Our cargo golf cartts are equipped with lithium battery. Lithium battery has about 5 times life cycles of lead acid battery, while the cost of our lithium battery pack is quite close to lead acid battery. All those make our cargo golf carts have lower life cost.

Lower Maintenance Cost

With same capacity, our lithium battery weights about 1/3 of lead acid battery. Our cargo golf cart with lithium battery is lighter than the one with lead acid battery. Less weight means less wears&tears to the cargo golf cart, also lithium battery is maintenance free, all those makes our cargo golf carts have lower maintenance cost

More Comfortable

Our cargo golf carts have front double wishbone Independent suspension, rear trailing arm suspension with shock absorber, and thick cold foamed sponge seat cushion which make them very comfortable to ride

Safer

Our cargo golf carts have 4-wheel hydraulic disc brake, automatic EM parking brake and regenerative brake, all those make our cargo golf cart very safe to ride.

  • Laminated Glass Windshield

  • Laminated Glass with Wiper

  • 2-point seatbelt

  • 3-point seatbelt

  • Front Brush Guard

  • Front Basket

  • 2-Tone Seat

  • Backrest with headrest

  • Backrest cover in wood finish

  • Backrest cover in carbon fibre

  • Dashboard in carbon fibre finish

  • Steering Wheel in wood finish

  • Inner Rear View Mirror

  • Enclosure (Rain Cover)

  • USB port

  • Under Roof/Chassis LED light

  • 12V Plug

  • Solar Panel
